chainflex® data cable CF299

Discontinued Model

1. Pressure extruded TPE compound 2. High flexural strength braiding of alloy wires 3. Gusset-filling extruded 4. 2 cores each stranded in one layer with particularly short pitch length 5. Conductor made of high flexural strength special alloy

1 of 3

For heaviest duty applications and especially small radii up to 4 x d
TPE outer jacket
Overall shield
Oil-resistant (following DIN EN 60811-404), resistant to bio oils (following VDMA 24568 with Plantocut 8 S-MB tested by DEA)
Bio-oil-resistant
Halogen-free
Silicone-free
PVC-free
UV-resistant
chainflex® class: 7.5.4.1

Item no.

This article is a discontinued model.

chainflex® CASE available

Typical application areas

For heaviest duty applications and especially small radii up to 4 x d
Almost unlimited resistance to oil, also with bio-oils
Indoor and outdoor applications, UV-resistant
Especially for short, very fast applications with small radii and restricted installation space
Pick and place machines, automatic doors, cleanroom, very quick handling

Guaranteed service life for this series according to guarantee conditions
Further information: chainflex® guarantee

Double strokes*	10 million	15 million	20 million
Temperature,	R min.	R min.	R min.
from/to [°C]	[Factor x d]	[Factor x d]	[Factor x d]
-35 / -25	5	6	7
-25 /+80	4	5	6
+80 / +90	5	6	7

* Higher number of double strokes possible - use the service life calculation function on this page.
