e-skin flat ESD ribbon cables

For ESD-sensitive parts in the cleanroom

Cleanroom-compatible up to ISO Class 1
New black e-skin flat in size SKF12 in openable and fully closed variants. Conductivity prevents electrostatic fields and abrupt discharges caused by e-skin flat movement.

Send an e-skin flat ESD query now

Technical data

Part No.	Series / Type	Inner height [mm]	Outer height [mm]	Number of chambers	Max. cable ø [mm]
SKF12C.1.1.10ESD	Closed	12	13	2 - 6	10
SKF12O.1.1.10ESD	openable	12	13	2 - 6	10

Tech up

Tried-and-tested e-skin flat system now also available in dissipative material
Optionally with internal e-skin® flat with support chain for unsupported lengths
Suitable for particularly small installation spaces in combination with CFCLEAN
Flexible design thanks to connectable individual pods
No further shielding of ESD-sensitive parts necessary

Cost down

Quick and easy replacement of the filling
All e-skin flat accessories can be used

Proof

Tests in the igus internal ISO Class 1 cleanroom laboratory
Initial tests for conductivity and cleanroom compatibility carried out in the igus laboratory

Sustainability

Conserves resources, as individual elements are interchangeable
Small installation space ‑ smallest possible cleanroom required
Components have no ESD faults due to
